6×37 is a cross laid construction used for general engineering applications. 6×37 is also available with IWRC (independent wire rope core). In the UK 6×36 is a far more popular construction, whilst on the European mainland, vast quantities of 6×37 are used for a variety of applications.
Applications
- General engineering applications
- Crane ropes
- Hoist rope
| Breaking Loads | |||||
|---|---|---|---|---|---|
| Nominal Diameter | Approximate Mass | Minimum Breaking Loads | |||
| 1770 Mpa | 1960 Mpa | ||||
| [mm] | [kg/m] | [kN] | [Kg] | [kN] | [Kg] |
12 | 0.498 | 75.2 | 7,669 | 83.3 | 8,492 |
13 | 0.585 | 88.2 | 9,000 | 97.7 | 9,967 |
14 | 0.678 | 102.3 | 10,438 | 113.3 | 11,559 |
16 | 0.886 | 133.7 | 13,634 | 148.0 | 15,098 |
18 | 1.121 | 169.2 | 17,256 | 187.3 | 19,108 |
20 | 1.384 | 208.9 | 21,303 | 231.3 | 23,590 |
22 | 1.675 | 252.7 | 25,777 | 279.8 | 28,544 |
24 | 1.993 | 300.8 | 30,677 | 333.0 | 33,970 |
26 | 2.339 | 353.0 | 36,003 | 390.9 | 39,868 |
28 | 2.713 | 409.4 | 41,755 | 453.3 | 46,237 |
30 | 3.114 | 469.9 | 47,933 | 520.4 | 53,078 |
32 | 3.543 | 534.7 | 54,537 | 592.1 | 60,391 |
34 | 4.000 | 603.6 | 61,567 | 668.4 | 68,176 |
36 | 4.484 | 676.7 | 69,024 | 749.3 | 76,433 |
38 | 4.996 | 754.0 | 76,906 | 834.9 | 85,161 |
40 | 5.536 | 835.4 | 85,214 | 925.1 | 94,362 |
42 | 6.103 | 921.1 | 93,949 | 1019.9 | 104,034 |
44 | 6.699 | 1010.9 | 103,110 | 1119.4 | 114,178 |
46 | 7.321 | 1104.9 | 112,696 | 1223.5 | 124,794 |
48 | 7.972 | 1203.0 | 122,709 | 1332.2 | 135,881 |
